DECO Lifts

Superior gear box design coupled with superior box-beam construction.

Overview: DECO’s heavy duty bronze worm gear reduction box is designed to be self-locking DECO’s superior gear box design is maintenance free, with drive gears fully enclosed and sealed in an oil bath DECO’s gear box and motor assembly connect directly to DECO’s dependable torque tube drive DECO’s direct drive provides a fast, smooth, and quiet operation DECO motors are continuous duty with sealed bearings and totally enclosed for the ultimate protection from the marine environment DECO drive produces a superior lift speed of 4 ft./min. on up to 6,000lb. capacity and 2 ft./min. on up to 30,000lb.

Standard Features Aluminum Box Beam Uppers and Lowers 5/16″ Stainless Steel Cable Grooved Cable Winders DECO Belt Drive (10′ elec.wire and maintained switches) Greased Pulley Bolts Four Chock Bunking System Stainless Steel Nuts and Bolts Motor Covers Available Options Remote Control Remote Control with Auto Stop Stainless Steel Motors Cable Retention System	Capacities: 4,000 lbs 6,000 lbs 10,000 lbs 13,000 lbs 16,000 lbs 20,000 lbs – 6 Pole 20,000 lbs – 4 Pole 25,000 lbs – 6 Pole 25,000 lbs – 8 Pole 30,000 lbs – 8 Pole 40,000 lbs – 8 Pole *Remote Control included on 25K, 30K, 40K Lifts
